Material and electroplating

Screws: M2.5    steel   zinc plating

Contact material: Brass nickel plated or stainless steel

Soldering pin: brass, tin plated

Plastic parts: PBT, UL94V-0

Electrical performance

Rated voltage: 300V

Rated current: 12A

Contact resistance: 20m ohm

Insulation resistance: 5000M ohm \1000V

Withstand voltage: AC1500V\1Min

Using line diameter: 14-22AWG  2.5mm2

Mechanical properties

Temperature range: -30 ~ 120 C

Instantaneous temperature: 250, 5 seconds

Torque: 0.5Nm (4.5lb.in)

Wire length: 4.5-5mm
