Material and electroplating

Screws: M3, steel, galvanized

Contacts: brass, nickel plated or stainless steel

Soldering pin: brass, tin plated

Plastic parts: PA66  UL94V-0

Electrical performance

Rated voltage: 300V

Rated current: 12A

Contact resistance: 20m ohm

Insulation resistance: 5000M ohm \1000V

Withstand voltage: AC1500V\1Min

Using line diameter: 22-12AWG  2.5mm2

Mechanical properties

Temperature range: -40 ~ 105 C

Instantaneous temperature: 250, 5 seconds

Torque: 0.4Nm (3.6lb.in)

Wire length: 4-5mm
